Ryobi RY46501A User Manual

OPERATOR’S MANUALELECTRIC CULTIVATORRY46501ASAVE THIS MANUAL FOR FUTURE REFERENCEYour electric cultivator has been engineered and manufactured to Ryob

10 11Fig. 3INSTALLING THE WHEEL ASSEMBLY ACCESSORYSee Figures 3 - 4.Use the wheel assembly accessory to transport the unit to and from the work area.

10 11WARNING: Do not allow familiarity with tools to make you care-less. Remember that a careless fraction of a second issufficient to inflic

12 13OPERATIONn Depress the switch lock-out.n Pull the switch trigger toward the handlebar to begin tine rotation.n To stop the cultivator, release

12 13OPERATIONGENERAL CULTIVATINGSee Figure 10.Shallow cultivating less than 2 in. deep can be used to disrupt weeds and aerate soil, without injuring

14 15ADJUSTMENTSWARNING:To prevent accidental starting that could cause serious personal injury, always disconnect the cultivator from any power sourc

14 15MAINTENANCEWARNING:When servicing, use only identical Ryobi replacement parts. Use of any other parts may create a hazard or caus

RYOBI TECHNOLOGIES, INC.1428 Pearman Dairy Road, Anderson, SC 29625Post Office Box 1207, Anderson, SC 29622-1207Phone 1-800-860-4050www.ryobitools.com

2 3n Introduction ...

2 3WARNING:READ AND UNDERSTAND ALL INSTRUCTIONS. Fail-ure to follow all instructions listed below may result in electric shock, fire, and/or seri

4 5n Do not use near underground electric cables, telephone lines, pipes, or hoses. If in doubt, contact your utility or telephone company to locate u

4 5SYMBOLSKeep Bystanders AwayCutting HazardEye ProtectionTo reduce the risk of injury, user must read and understand operator’s manual befo

6 7SYMBOLSSERVICEServicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we

6 7EXTENSION CORDSWhen using a power tool at a considerable distance from a power source, be sure to use an extension cord that has the capacity to

8 9FEATURESFig. 1PRODUCT SPECIFICATIONSInput .......

8 9WARNING:Do not connect to power supply until assembly is com-plete. Failure to comply could result in accidental starting and possible serious pers
